1-Streamlined appearance design, low fuel consumption and wide operating range.
2-Have CE certificate meet European market request.
3-Equip with hydraulic joystick, quick hitch, 4WD of 20.5/70-16 tractor pattern tire, heater, boom damp function, LED lamp, big screen reverse camera, warning light, adjustable suspension seat.
4-Optional pallet forks, 4in1 bucket, wood/grass grab, snow blade, sweeper etc. attachments.
5-LAIDONG, CHANGCHAI, YANMAR, KOHLER, CUMMINS engine for optional, meet EURO2, EURO5 and EPA4 rule.
Main parameters:
1.0 Engine |
(1) Brand/Model | YUNNEI YN25GBZ |
(3) Rated Power | 37KW / 2200r/min |
2.0 Overall Dimensions |
(1) Overall Length | 5800mm |
(2) Overall Width | 1800mm |
(3) Overall Height | 2680mm |
(4) Bucket Max. lifting height | 4400mm |
(5) Bucket Max. unloading height | 3400mm |
3.0 Transmission System Gearbox Hydraulic converter + Drive shaft + ISUZU axle |
4.0 Bucket |
(1) Capacity | 0.65 m³ |
(2) Max. Load | 1500kg including bucket or attachment |
5.0 Tire |
(1) tire Size | 20.5/70-16 |
6.0 Operating weight | 4200KG |
The above information, specifications and images may be different from actual machines and may be changed without prior notice for performance improvement. Please contact our sales office for exact model option and specification.
FORLOAD reserves the right to change specifications and equipment without notice to suit local conditions and requirements.
