WZ30-25M
FORLOAD
8429510000
| Overall Operating Weight | 7640KG | Final Reducer | Single Stage Final Reducer |
| Transport Dimension | Rated Loader of Axle | 7.5t | |
| L*W*H | 5910×2268×3760mm | Transmission System | |
| Wheel base | 2250mm | Torque Converter | |
| Min. Ground Clearance | 300mm | Model | YJ280 |
| Bucket Capacity | 1.2m3 | Breakout Force | 38KN |
| Loading Lifting Capacity | 2500KG | Bucket dumping height | 2742mm |
| Bucket Dumping Distance | 1062mm | Digging depth | 52mm |
| Backhoe Capacity | 0.3m3 | Gearbox Type | Fixed Shaft Power Transmission |
| Max. Digging Depth | 4082mm(4500mm) | Oil Pressure of Clutch | 1373Kpa-1569 Kpa |
| Swing Angle of Excavator Grab | 190o | Gears | Two Gears Ahead, Two Gears Astern |
| Max. Pulling Force | 39KN | Max.Speed | 22Km/h |
| Engine | Tyre | ||
| Model | CYD YC4A105Z-T20 | Model | 16/70-20 |
| Cylinder-Inside Diameter*Stroke | 4-102×120 | Engine power | 75KW |
| Overall Operating Weight | 7640KG | Final Reducer | Single Stage Final Reducer |
| Transport Dimension | Rated Loader of Axle | 7.5t | |
| L*W*H | 5910×2268×3760mm | Transmission System | |
| Wheel base | 2250mm | Torque Converter | |
| Min. Ground Clearance | 300mm | Model | YJ280 |
| Bucket Capacity | 1.2m3 | Breakout Force | 38KN |
| Loading Lifting Capacity | 2500KG | Bucket dumping height | 2742mm |
| Bucket Dumping Distance | 1062mm | Digging depth | 52mm |
| Backhoe Capacity | 0.3m3 | Gearbox Type | Fixed Shaft Power Transmission |
| Max. Digging Depth | 4082mm(4500mm) | Oil Pressure of Clutch | 1373Kpa-1569 Kpa |
| Swing Angle of Excavator Grab | 190o | Gears | Two Gears Ahead, Two Gears Astern |
| Max. Pulling Force | 39KN | Max.Speed | 22Km/h |
| Engine | Tyre | ||
| Model | CYD YC4A105Z-T20 | Model | 16/70-20 |
| Cylinder-Inside Diameter*Stroke | 4-102×120 | Engine power | 75KW |
