| Quantity: | |
|---|---|
Overall Operating Weight | 4500KG |
Transport Dimension | |
L*W*H | 6800x2100x2980mm |
Min. Ground Clearance | 300mm |
Front bucket Capacity | 0.8m3 |
Front bucket loading Lifting Capacity | 1800KG |
Bucket Dumping Height | 2700mm |
Backhoe Capacity | 0.18m3 |
Max. Digging Depth | 2600mm |
Engine | |
Model | YUNNEI YN27GBZ Turbo |
Type | In Line,Direct injection,Four-Stroke,Water Cooling |
Rated Power | 58KW |
Rated Speed | 2400r/min |
Optional engine | XINCHAI EURO3 or EURO5 YANMAR EPA3 or CUMMINS EPA4 |
Steering System | |
Steering Angle | ±35 o |
Min. turning radius | 4800mm |
Pressure of the system | 12Mpa |
Axle | |
Model | Wheel hub reducer drive axle |
Drive type | Four-wheel drive |
Transmission System | |
Torque Converter | |
Model | YJ265 |
Cooling Method | Oil-cooling Pressure Circulation |
Gearbox | |
Type | Power Transmission |
Gears | Two Gears forward, Two Gears reverse |
Max. Speed | 28Km/h |
Optional Gears | Four Gears forward, Four Gears reverse |
Max. Speed | 33Km/h |
Tire | |
Size | 23.5/70-16 |
Pressure of Front wheel | 0.22 Mpa |
Pressure of Back Wheel | 0.22 Mpa |
Brake System | |
Service Brake | Air Over Oil Caliper Brake |
External Type | |
Self-regulation | |
Self-balance | |
Emergency Brake | Operation Power Implementing brake |
Manual Operation Power Terminating Brake | |
Hydraulic System | |
Pressure of Hydraulic System | 22Mpa |
The parameters or configuration are subject to change without notice. | |
Overall Operating Weight | 4500KG |
Transport Dimension | |
L*W*H | 6800x2100x2980mm |
Min. Ground Clearance | 300mm |
Front bucket Capacity | 0.8m3 |
Front bucket loading Lifting Capacity | 1800KG |
Bucket Dumping Height | 2700mm |
Backhoe Capacity | 0.18m3 |
Max. Digging Depth | 2600mm |
Engine | |
Model | YUNNEI YN27GBZ Turbo |
Type | In Line,Direct injection,Four-Stroke,Water Cooling |
Rated Power | 58KW |
Rated Speed | 2400r/min |
Optional engine | XINCHAI EURO3 or EURO5 YANMAR EPA3 or CUMMINS EPA4 |
Steering System | |
Steering Angle | ±35 o |
Min. turning radius | 4800mm |
Pressure of the system | 12Mpa |
Axle | |
Model | Wheel hub reducer drive axle |
Drive type | Four-wheel drive |
Transmission System | |
Torque Converter | |
Model | YJ265 |
Cooling Method | Oil-cooling Pressure Circulation |
Gearbox | |
Type | Power Transmission |
Gears | Two Gears forward, Two Gears reverse |
Max. Speed | 28Km/h |
Optional Gears | Four Gears forward, Four Gears reverse |
Max. Speed | 33Km/h |
Tire | |
Size | 23.5/70-16 |
Pressure of Front wheel | 0.22 Mpa |
Pressure of Back Wheel | 0.22 Mpa |
Brake System | |
Service Brake | Air Over Oil Caliper Brake |
External Type | |
Self-regulation | |
Self-balance | |
Emergency Brake | Operation Power Implementing brake |
Manual Operation Power Terminating Brake | |
Hydraulic System | |
Pressure of Hydraulic System | 22Mpa |
The parameters or configuration are subject to change without notice. | |
