1-Streamlined appearance design, low fuel consumption and wide operating range.
2-Have CE certificate meet European market request.
3-Much suitable for loosing soil of vegetable greenhouse, campus greening of municipal departments, digging the hole for tree, planting of fruit-land nurseries, concrete pavement crushing, sand-gravel material mixing, construction working in narrow place and so on.
4-Optional hydraulic quick hitch, hammer, ripper, auger, thumb, different size buckets.
Model | TBE18SU |
Operating mode | Hydraulic lever |
Operating weight | 1800 kg |
Bucket capacity | 0.07 cbm |
Bucket width | 430mm (any size can be customized) |
Engine | KUBOTA D902 EURO5/EPA4, 11.8kw |
Pump | SHIMADZU |
Valve | HUSCO（USA） |
Walking motor | EASTON OMB195 (USA) |
Rotary motor | EASTON brand |
Cylinder | Three-cylinder, Water cooling |
Walking speed | 2.5km/h |
Track type | Rubber Track |
Physical Size | |
Track length*width | 1450mm*230mm |
Distance from bulldozer to ground | 265 mm |
Chassis width | 1100 mm |
Working Range | |
Max. digging depth | 2050 mm |
Max. digging height | 3350 mm |
Dump height | 2400 mm |
Max. digging radius | 3650 mm |
System pressure | 16MPA |
