1-Streamlined appearance design, low fuel consumption and wide operating range.
2-Have CE certificate meet European market request.
3-Equip with WEICHAI powerful engine, 4th hydraulic joystick, quick hitch, 4WD of 17.5-25 tractor
pattern tire, heater, boom damp function etc.
4-Optional pallet forks, 4in1 bucket, wood/grass grab, snow blade, sweeper etc. attachments.
Main specification:
1.0 Engine | |
(1) Brand/Model | WEICHAI |
(2) Rated Power | 92KW |
2.0 Overall Dimensions | |
(1) Overall Length | 7500mm |
(2) Overall Width | 2280mm |
(3) Overall Height | 3200mm |
(4) Bucket hinge pin Height: | 6000mm |
(5) Bucket Max. lift height | 6500mm |
(6) Bucket Max. unloading height | 5200mm |
3.0 Transmission System 315 Gearbox Hydraulic converters + Drive shaft +28 Hub reduction axle | |
4.0 Bucket | |
(1) Capacity | 1.7m³ |
(2) Width | 2280mm |
(3) Type | Heavy-duty bolt on teeth |
(4) Max. Load: | 3500kg including bucket or attachment |
5.0 Operating Specifications | |
(1) Steering System | Articulated hydraulic steering |
(2) Driving System | Four-wheel drive |
(3) Hydraulic quick release | Yes |
(4) Hydraulic pilot joystick | Yes |
(5) Steady rise | Yes |
6.0 Brake System | |
(1) Service Brake | Four-wheel disc brake |
(2) Parking Brake | Disc brake |
7.0 Tire | |
(1) Model | 17.5-25 Herringbone Tire |
(2) Size | Width: 440mm Diameter: 1280mm |
8.0 Wheelbase: 2800mm | |
9.0 Track: 1750mm | |
10.System pressure | 20Mpa |
11. Weight | 8000KG |
Reserve the right to change the parameters and design without prior notice.
