1-Streamlined appearance design, low fuel consumption and wide operating range.
2-Have CE certificate meet European market request.
3-Equip with 4th hydraulic joystick, quick hitch, 4WD of 16/70-20 tractor pattern tire, heater, boom damp function etc.
4-Optional pallet forks, 4in1 bucket, wood/grass grab, snow blade, sweeper etc. attachments.
Engine | |
(1) Brand/Model | Yunnei YN33GBZ |
(2) Type | In-line arrangement, water-cooled, four-cylinder, turbocharged diesel engine |
(3) Rated Power | 65KW |
(4) Optional Model | DF CUMMINS 74KW engine, or CUMMINS EPA4 engine |
Overall Dimensions | |
(1) Overall Length | 6200mm |
(2) Overall Width | 2000mm |
(3) Overall Height | 2760mm |
(4) Bucket hinge pin Height: | 4500mm |
(5) Telescopic stroke | 1100mm |
(6) Extend the arm length | 2950mm |
(7) Bucket Max. lifting height | 5100mm |
(8) Bucket Max. unloading height | 3900mm |
Transmission System Gearbox+Hydraulic converter + Drive shaft + Hub reduction axle | |
Bucket | |
(1) Capacity | 1m³ |
(2) Width | 2000mm |
(3) Type | Heavy-duty bolt on teeth |
(4) Max. Load: | 2000kg including bucket or attachment |
Operating Specifications | |
(1) Steering System | Articulated hydraulic steering |
(2) Driving System | Four-wheel drive |
(3) Hydraulic quick release | Yes |
(4) Mechanical pilot joystick | Yes |
(5) Steady rise | Yes |
Brake System | |
(1) Service Brake | Four-wheel disc brake |
(2) Parking Brake | Disc brake |
Tire | |
(1) Model | 16/70-20 Herringbone Tire |
(2) Size | Width: 380mm Diameter: 1075mm |
Wheel base: 2550mm | |
Track: 1600mm | |
System pressure | 20Mpa |
Weight | 5500KG |
