H928M
FORLOAD
8429510000
1-Streamlined appearance design, elegant and generous.
2-Fully hydraulic steering system, electric joystick and quick hitch to make sure easily operation.
3-New Rops/Fops luxury cabin, equipment air suspension seat, heater, warning lamp, reverse camera; the operating environment is more comfortable.
4-Quick hitch and 4th extra hydraulic line are standard equipment, to make sure can use different accessories and meet different working usage: pallet fork, 4in1 bucket, high dump bucket, wood/grass grab, snow blower, snow V-blade, sweeper, snow bucket with hydraulic wing, hammer etc.
5-Equip more practical functions: boom damp/floating function, emergency stop button, intelligent electric box,
6-Streamline new heavy type counterweight, heavy axle, new rotary type articulated joint, LED dashboard, Z type connecting rod.
7-DF CUMMINS 74KW engine, XINCHAI EURO5 engine are optional; Air conditioner optional.
Performance | Model | H928M |
Rated loading | 2500kg | |
Operation weight | 6000kg | |
Rated bucket capacity | 1.2m3 | |
Max. Dump height | 2800~3500mm | |
Dump distance | 930mm | |
Overall dimension (LxWxH) | 6170x2040x2695mm | |
Engine | Model | YUNNEI YN38GBZ (or DF CUMMINS, or XINCHAI EURO5 ) |
Rated power | 76KW / 2400rpm | |
Transmission system | Torque converter | ZL265 |
Gearbox mode | Countershaft, power-shift | |
Gear shift | Electric shift type, 2 forward, 2 reverse. | |
Max. Speed | 30km/h | |
Drive axle | Main reducing spiral | Circular Arc Bevel gear, single stage |
Decelerating mode | Single stage planetary type | |
Wheelbase | 2670mm | |
Tire | Tyre size | 16/70-20 |
With continue updating design, we reserve the right to change the parameters and design without prior notice.
1-Streamlined appearance design, elegant and generous.
2-Fully hydraulic steering system, electric joystick and quick hitch to make sure easily operation.
3-New Rops/Fops luxury cabin, equipment air suspension seat, heater, warning lamp, reverse camera; the operating environment is more comfortable.
4-Quick hitch and 4th extra hydraulic line are standard equipment, to make sure can use different accessories and meet different working usage: pallet fork, 4in1 bucket, high dump bucket, wood/grass grab, snow blower, snow V-blade, sweeper, snow bucket with hydraulic wing, hammer etc.
5-Equip more practical functions: boom damp/floating function, emergency stop button, intelligent electric box,
6-Streamline new heavy type counterweight, heavy axle, new rotary type articulated joint, LED dashboard, Z type connecting rod.
7-DF CUMMINS 74KW engine, XINCHAI EURO5 engine are optional; Air conditioner optional.
Performance | Model | H928M |
Rated loading | 2500kg | |
Operation weight | 6000kg | |
Rated bucket capacity | 1.2m3 | |
Max. Dump height | 2800~3500mm | |
Dump distance | 930mm | |
Overall dimension (LxWxH) | 6170x2040x2695mm | |
Engine | Model | YUNNEI YN38GBZ (or DF CUMMINS, or XINCHAI EURO5 ) |
Rated power | 76KW / 2400rpm | |
Transmission system | Torque converter | ZL265 |
Gearbox mode | Countershaft, power-shift | |
Gear shift | Electric shift type, 2 forward, 2 reverse. | |
Max. Speed | 30km/h | |
Drive axle | Main reducing spiral | Circular Arc Bevel gear, single stage |
Decelerating mode | Single stage planetary type | |
Wheelbase | 2670mm | |
Tire | Tyre size | 16/70-20 |
With continue updating design, we reserve the right to change the parameters and design without prior notice.
