FORLOAD brand forklift, loading capacity covers 1.5tons to 10tons, to meet different customer’s different request.
More information please free feel to contact with us.
Model | CPC25 | CPC30 | CPC35 | CPC40 | CPC50 |
Power type | Diesel | Diesel | Diesel | Diesel | Diesel |
Rated loading capacity | 2500kgs | 3000kgs | 3500kgs | 4000kgs | 5000kgs |
Loading center | 500mm | 500mm | 500mm | 500mm | 500mm |
Lifting height | 3000mm | 3000mm | 3000mm | 3000mm | 3000mm |
Fork size | 1070x122x40mm | 1070x125x45mm | 1070x125x50mm | 1070x150x50mm | 1220x150x55mm |
Mast tilt angle | 60/120 | 60/120 | 60/120 | 60/120 | 60/120 |
Min. turning radius | 2250mm | 2400mm | 2550mm | 2800mm | 3050mm |
Min. ground clearance | 120mm | 135mm | 135mm | 120mm | 140mm |
Overhead guard height | 2150mm | 2160mm | 2160mm | 2230mm | 2290mm |
Max. speed | 19km/h | 20km/h | 20km/h | 19km/h | 19km/h |
Max. lifting speed | 500mm/m | 460mm/m | 460mm/m | 420mm/m | 400mm/m |
Max. traction | 18kn | 20kn | 22kn | 20kn | 22kn |
Max. gradeability | 20% | 20% | 20% | 20% | 20% |
Length with fork | 3710mm | 3780mm | 3920mm | 4105mm | 4590mm |
Length without fork | 2540mm | 2700mm | 2850mm | 3035mm | 3370mm |
Width | 1160mm | 1226mm | 1226mm | 1400mm | 1480mm |
Mast extended height | 4220mm | 4265mm | 4265mm | 4270mm | 4300mm |
Mast lowered height | 2060mm | 2060mm | 2060mm | 2190mm | 2190mm |
Front tire | 7.00-12-12PR | 28x9-15-12PR | 28x9-15-12PR | 250-15-16PR | 300-15-20PR |
Rear tire | 6.00-9-10PR | 6.50-10-10PR | 6.50-10-10PR | 7.00-12-12PR | 7.00-12-12PR |
wheelbase | 1600mm | 1700mm | 1850mm | 1900mm | 2100mm |
Service weight | 3880kgs | 4350kgs | 4560kgs | 5300kgs | 7000kgs |
Engine | XINCHAI 498BPG, 4 cylinders | XINCHAI 498BPG, 4 cylinders | XINCHAI 495, 4 cylinders | XINCHAI 495, 4 cylinders | LR4B32U, 4 cylinders |
Engine power | 37kw/2500rpm | 37kw/2500rpm | 42kw/2500rpm | 42kw/2500rpm | 65kw/2400rpm |
Rated torque | 156Nm | 156Nm | 168Nm | 168Nm | 302Nm |
Fuel tank | 60L | 70L | 70L | 80L | 120L |
Working pressure | 17.5Mpa | 17.5Mpa | 17.5Mpa | 20Mpa | 20Mpa |
Transmission | Manual | Manual | Manual | Manual | Hydraulic |
Optional: 3 stage 4.5/6m triplex mast, side shift, solid tire, closed cabin, ISUZU/YANMAR/MITSUBISHI engine, all kinds of accessories.
With continue updating design, we reserve the right to change the parameters and design without prior notice.
