FL340PC-9
FORLOAD
8427209000
Performance feature:
1-Exclusive highly efficient hydraulic control system.
2-Engine adopt ISUZU or CUMMINS brand.
3-Main pump is KAWASAKI brand.
4-Control valve: KAWASAKI or PARKER brand.
5-Travel motor: SUNJIN (Korean brand) or EATON or Doosan equip brand.
6-Swing motor: SUNJIN (Korean brand) or EATON or Doosan equip brand.
7-Powerful travel traction, effectively prevent mixing of soil and rock, highly efficient and rapid operation, high-strength frame structure and greater ground clearance, safe and open engine hood, convenient to maintenance.
Main specification:
Model | FL340PC-9 |
Operation weight | 31000~33000kgs |
Bucket capacity | 1.6m3 |
Engine | |
Engine model | Original ISUZU or CUMMINS |
Engine power | 148kw~169kw |
Performance | |
Swing speed | 10.1rpm |
Walking speed | 5.7/3.2 km/h |
Ground specific pressure | 57kpa |
Bucket digging force | 187kn / 198kn |
Bucket boom digging force | 131kn / 139kn |
Boom length | 6245mm |
Arm length | 3100mm |
Hydraulic system | |
Main pump type | KAWASAKI brand, variable displacement piston pump |
Main pump max. flow | 2x211 L/min |
Walking hydraulic motor | Axial plunger type |
Swing hydraulic motor | Axial plunger type |
Swing hydraulic oil pressure | 27.5Mpa |
Walking hydraulic oil pressure | 32.4Mpa |
Fuel tank capacity | |
Diesel fuel tank | 450L |
Hydraulic oil tank | 290L |
Engine oil | 42L |
Cooling liquid | 42L |
Main dimension | |
Transport length | 10620mm |
Transport width | 3200mm |
Transport height | 3365mm |
Chain length | 4930mm |
Chain plate width | 600mm |
Chain total width | 3200mm |
Chain track distance | 2600mm |
Minimum ground clearance | 1175mm |
rear-end swing radius | 3200mm |
Working range dimension | |
Max. digging radius | 10705mm |
Max. digging depth | 7190mm |
Max. digging height | 10495mm |
Max. dump height | 7470mm |
Max. digging depth (vertical) | 6220mm |
The above information, specifications and images may differ from actual vehicle and may be changed without prior notice for performance improvement. Please contact our sales office for exact model option and specification.
FORLOAD reserves the right to change specifications and equipment without notice to suit local conditions and requirements.
