T100
FORLOAD
8429119000
1. Engine: Choose the engine produced with British Ricardo joint-venture technology, which conforms to National III emission standard, and Common rail, features low noise, large torque, energy efficient and environmental friendliness.
2. Main clutch: Choose dry, multi-disk and constant combining clutch which features big torque reserve and high reliability.
3. Gearbox: Choose 4F+2R mechanical gear-shifting gearbox, simply operating, conveniently maintaining, reliably using.
4. Steering clutch: Choose dry and multi-disk turning clutch, manually operating with hydraulically assisted, easily maintaining, lightly and conveniently operating.
5. Transmission: Choose two stages, straight teeth, big modulus gear transmission, stronger carrying capacity, and higher reliability.
6. Cab: Adopt the luxury cab, overhead air-conditioning system, comfortable operating space.
7. Optional work device: Straight-tilt shovel, angle shovel， coal shovel and so on.
Model | T100 |
Dimension (LxWxH) | 4190x2935x3020mm |
Total weight | 10400kgs |
Chain width | 450mm |
Average ground pressure | 54.4kPa (with front blade) |
Engine model | LR6A3LU23/0810E (YTO brand) |
Rated power | 81kw at 2300 rpm |
Towing equipment / ripper (optional) | Fixed type. (Ripper is three teeth type) |
Front blade type | Fixed straight blade |
Blade size (HxW) | 960x2935mm |
Blade working depth | ≥350mm |
Blade maximum lifting height | ≥830mm |
Forward 1~4 gearshift | 2.6~10.4 km/h |
Reverse 1~2 gearshift | 3.7~6.7 km/h |
Reserve the right to change the parameters and design without prior notice.
1. Engine: Choose the engine produced with British Ricardo joint-venture technology, which conforms to National III emission standard, and Common rail, features low noise, large torque, energy efficient and environmental friendliness.
2. Main clutch: Choose dry, multi-disk and constant combining clutch which features big torque reserve and high reliability.
3. Gearbox: Choose 4F+2R mechanical gear-shifting gearbox, simply operating, conveniently maintaining, reliably using.
4. Steering clutch: Choose dry and multi-disk turning clutch, manually operating with hydraulically assisted, easily maintaining, lightly and conveniently operating.
5. Transmission: Choose two stages, straight teeth, big modulus gear transmission, stronger carrying capacity, and higher reliability.
6. Cab: Adopt the luxury cab, overhead air-conditioning system, comfortable operating space.
7. Optional work device: Straight-tilt shovel, angle shovel， coal shovel and so on.
Model | T100 |
Dimension (LxWxH) | 4190x2935x3020mm |
Total weight | 10400kgs |
Chain width | 450mm |
Average ground pressure | 54.4kPa (with front blade) |
Engine model | LR6A3LU23/0810E (YTO brand) |
Rated power | 81kw at 2300 rpm |
Towing equipment / ripper (optional) | Fixed type. (Ripper is three teeth type) |
Front blade type | Fixed straight blade |
Blade size (HxW) | 960x2935mm |
Blade working depth | ≥350mm |
Blade maximum lifting height | ≥830mm |
Forward 1~4 gearshift | 2.6~10.4 km/h |
Reverse 1~2 gearshift | 3.7~6.7 km/h |
Reserve the right to change the parameters and design without prior notice.
